: Interfaces and Modules
Hardware Accelerated GE RJ45 WAN / DMZ Ports :1
Hardware Accelerated GE RJ45 Internal Ports : 3
Hardware Accelerated GE RJ45 FortiLink Ports (Default) : 1
Hardware Accelerated GE RJ45 PoE/+ Ports : 0
Wireless Interface : 0
USB Ports : 1
Console Port (RJ45) : 1
Onboard Storage : 0
Included Transceivers : 0
: System Performance — Enterprise Traffic Mix
IPS Throughput : 2,1Gbps
NGFW Throughput 2, 4 : 800 Mbps
System Performance and Capacity
IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) : 5 / 5 / 5 Gbps
Firewall Latency (64 byte, UDP) : 2.97μs
Firewall Throughput (Packet per Second) : 7.5 Mpps
Concurrent Sessions (TCP) : 700000
New Sessions/Second (TCP) : 35000
Firewall Policies : 5000
IPsec VPN Throughput (512 byte) 1 : 4.4 Gbps
Gateway-to-Gateway IPsec VPN Tunnels : 200
Client-to-Gateway IPsec VPN Tunnels : 250
SSL-VPN Throughput : 490 Mbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) : 200
SSL Inspection Throughput (IPS, avg. HTTPS) : 310 Mbps
SSL Inspection CPS (IPS, avg. HTTPS)3 : 320
SSL-VPN Throughput 490 Mbps
SSL Inspection Concurrent Session (IPS, avg. HTTPS)3 : 55000
Application Control Throughput (HTTP 64K) 2 : 990Mbps
CAPWAP Throughput (HTTP 64K) : 3.5Gbps
Virtual Domains (Default / Maximum) : 10/10
Maximum Number of FortiSwitches Supported : 8
Maximum Number of FortiAPs (Total / Tunnel) ; 16/8
Maximum Number of FortiTokens : 500
Maximum Number of Registered FortiClients : 20000
High Availability Configurations : Active, Active-Active, Passive, Clustering
Dimensions and Power
Height x Width x Length (inches) : 1.5 x 8.5 x 6.3
Height x Width x Length (mm) : 38.5 x 216 x 160
Weight : 1kg
Form Factor : Desktop
Input Rating : 12Vdc, 3A
Power Required : Powered by External DC Power Adapter, 100–240V AC, 50–60 Hz
Power Consumption (Average / Maximum) : 13.4 W / 15.4 W
Current (Maximum) : 100V AC / 0.2A, 240V AC / 0.1A
Heat Dissipation : 52.55 BTU/h
Operating Environment and Certifications
Operating Temperature : 32–104°F (0–40°C)
Storage Temperature : -31–158°F (-35–70°C)
Humidity : 10–90% non-condensing
Noise Level : Fanless 0 dBA
Operating Altitude : Up to 7,400 ft (2,250 m)
Certifications : ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN
